JIS K6264 Lab Akron Abrasion Tester For Footwear

Name: JIS K6264 Lab Akron Abrasion Tester For Footwear
Brand: GESTER
Price: 1 USD

Cheap JIS K6264 Lab Akron Abrasion Tester For Footwear wholesale

Brand Name : GESTER

Model Number : GT-KB04

Certification : CE,ISO

Place of Origin : CHINA

MOQ : 1 set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 sets/month

Delivery Time : 10-30 days

Packaging Details : wooden packaging

Product name : Foorwear Lab Rubber Shoe Akron Abrasion Tester

Certificate : CE ISO

Warranty : 1 Year

Dimension : 615*515*500mm

Weight : 60kg

Control : Electronic Control

Counter : LCD, 0-99,999,999

Loading Method : Dynamic Load

Power Supply : 220V 50/60Hz

Maxcapacity : <1000KN

Contact Now

Foorwear Lab Rubber Shoe Akron Abrasion Tester

Application
Foorwear Lab Rubber Shoe Akron Abrasion Tester to determine wear resistance of vulcanized rubber and elastic material products, like shoes sole, tires, vehicle tracks, by measuring its wear volume caused by rubbing between specimen and sandwheel. And it need to test with balance.

Feature
1. Body paint baking processed, easy for mainteance.
2. Electronic automatical counter can set wear revolutions and it will automatically stop when it reaches set revolutions.

Key Specification

Model	GT-KB04A	GT-KB04B			GT-KB04C
Sand Wheel	Outer Diameter Φ150mm, 25mm(w), granularity 36#, Abrasive material: Alumina
Rubber wheel	Outer diameter 68mm, Thickness 12.7mm, Perimeter 220mm	Outer diameter 60mm, Inner diameter 12.7mm, Thickness 13mm			Outer diameter 63.5mm, Inner diameter 12.7mm, Thickness 12.5mm
Rubber axle inclination angle range	0~35° adjustable(test angle 15° or 25°)
Rubber axle rotating speed	76±2 rpm		75±5rpm or 250±5rpm		250±5 rpm
Load	26.7±0.2N		27.0N or 44.1N		45N
Counter	LCD, 0~99,999,999
Dimensions ( L x W x H )	60 × 50 × 45cm
Weight	60 kg
Power	AC220V, 50/60Hz
Standards	GB/T1689		JIS K6264	BS-903-A9 Method B

Accessories

Standards accessories

1pc

Rubber wheel

1pc

Grinding wheel

1set

Weights
